HXGN China supplier 6kv power distribution ring main switchgear

HXGN China supplier 6kv power distribution ring main switchgear

    • HXGN China supplier 6kv power distribution ring main switchgear
    • HXGN China supplier 6kv power distribution ring main switchgear
  • HXGN China supplier 6kv power distribution ring main switchgear

    Product Details:

    Place of Origin: Zhejiang
    Brand Name: Ptox Corp
    Model Number: HXGN-12

    Payment & Shipping Terms:

    Price: 8065Set
    Payment Terms: L/C,T/T,Western Union,MoneyGram,Paypal
    Supply Ability: 30 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Min.Order: 1 Port: Shanghai, Guangzhou, Shenzhen, Chongqin,Ningbo
    FOB: 8 Product Name: Ring Main Switchgear
    Material: CRCA Rated Voltage: 12kV
    Rated Frequency: 50Hz Rated Transfer Current: 1700A
    Application: Industrial Protection Degree: Up To IP3X

    HXGN China supplier 6kv power distribution ring main switchgear

    HXGN China supplier 6kv power distribution ring main switchgear

    HXGN China supplier 6kv power distribution ring main switchgear

    Features

    • Compact modular design
    • Simple structure, small volume and light weight
    • Ease and flexible for installation
    • Reliable and safe to operate
    • Low operating cost

    Product Description

    It is a new product self-designed and self-developed by introducing oversea advanced techniques and the requirements of rural and urban power network reform. The core parts are load switch, switch-fuse combinations or circuit breaker.

    Application

    It is applicable to the ring network or terminal power supply system with three-phase AC 50Hz, rated voltage of 12kV, rated current of up to 630A. It is widely used in the load center powder distribution station of urban residential area, high-rise building, large public buildings, factories and enterprises as power receiving and distribution or overload protection, short circuit protection; As a ring network power supply unit and terminal equipment, it plays role in the power distribution, power controlling and electrical equipment protection, so it is widely installed in prefabricated substations.

    Normal Conditions

    • Ambient air temperature : -5°C ~ +40°C;
    • Daily average temperature(Within 24h): ≤+35℃
    • Altitude:≤1000m;
    • Relative humidity: within 24h, daily average value ≤ 95% , daily average vapor pressure≤ 2.2KPa; monthly average value ≤ 90%, monthly average vapor pressure≤ 1.8KPa
    • Ambient air is not significantly polluted by dust, smoke, corrosive and / or flammable gas, vapor or salt contamination.

    Special Conditions


    If the switchgear will be used in conditions that exceed the normal environmental conditions, users should consult with the manufacturer.

    Product Parameter

    Item(Unit)

    Data

    Load Switch

    Switch-fuse Combinations

    Rated Voltage(kV)

    12

    Rated Current(A)

    630

    125

    Rated Frequency(Hz)

    50

    Rated Short-time Power Frequency Withstand Voltage(kV)

    42

    Rated Lightning Impulse Withstand Voltage(kV)

    75

    Rated Peak Withstand Current(kA)

    20

    4S Rated Short-time Withstand Current(kA)

    50

    Rated Short-circuit Making Current(kA)

    50

    80

    Rated Power load Drop-out Current(A)

    630

    Rated Short-circuit Drop-out Current(kA)

    31.5

    Rated Transfer Current(A)

    1700

    Standard

    GB3906,GB3804

    GB3906,GB12926

    Protection Degree

    ≤IP3X

    HXGN China supplier 6kv power distribution ring main switchgear

    HXGN China supplier 6kv power distribution ring main switchgear

    HXGN China supplier 6kv power distribution ring main switchgear

    HXGN China supplier 6kv power distribution ring main switchgear

    HXGN China supplier 6kv power distribution ring main switchgear

    HXGN China supplier 6kv power distribution ring main switchgear HXGN China supplier 6kv power distribution ring main switchgear HXGN China supplier 6kv power distribution ring main switchgear

    HXGN China supplier 6kv power distribution ring main switchgear
