GCS1 fixed separated switchgear equipment

GCS1 fixed separated switchgear equipment

    • GCS1 fixed separated switchgear equipment
    • GCS1 fixed separated switchgear equipment
    • GCS1 fixed separated switchgear equipment
    • GCS1 fixed separated switchgear equipment
  • GCS1 fixed separated switchgear equipment

    Product Details:

    Place of Origin: Zhejiang of China
    Brand Name: Ptox Corp
    Certification: ISO,CCC
    Model Number: GCS1

    Payment & Shipping Terms:

    Price: 9678Set
    Payment Terms: L/C,T/T,Western Union,MoneyGram,Paypal
    Supply Ability: 30 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Min.Order: 1 Port: Shanghai, Guangzhou, Shenzhen, Chongqin,Ningbo
    FOB: 9 Product Name: Switchgear Equipment
    Material: CRCA Rated Working Voltage: AC380V
    Rated Insulation Voltage: AC660V Rated Frequency: 50Hz
    Protection Degree: IP30 Type: Switchgear Equipment
    Standard: GB7251.12

    GCS1 fixed separated switchgear equipment

    Features

    • Good practicability
    • Flexible design
    • High security
    • High reliability

    Description

    GCS1 fixed separated switchgear equipment is a domestic advanced product, based on the withdrawable switchgear and self-developed according to the user's powder distribution special requirement and project practicability.

    Application

    GCS1 fixed separated switchgear equipment is widely applied to power distribution system and powder control center of power plants, petroleum, chemical, metallurgical ,textile and high-rise buildings. They are applicable to three-phase four-wire and three-phase five-wire power systems with three-phase AC 50, rated voltage 380V and rated current 6,300A and below as power acceptation and distribution. The device can be divided into power distribution center (PC Cabinet) and motor control center (MCC cabinet) by its application.

    Normal operating conditions

    • Ambient air temperature : -5°C ~ +40°C;
    • Daily average temperature(Within 24h): +35
    • Relative humidity: 50% at the maximum temperature of +40 and may be higher at lower temperature, for example, 90% at +20.
    • Altitude:2,000m;
    • Installation inclination: 5°;
    • Installation places: Indoor; without fire, explosion risk, serious pollution, rain immersion, violent vibration,chemical corrosion and conductive dust.

    Special operation conditions
    If the switchgear will be used in conditions that exceed the normal environmental conditions, users should consult with the manufacturer.

    Technical Parameter

    No.

    Item(Unit)

    Data

    1

    Rated Working Voltage(V)

    AC380

    2

    Rated Insulation Voltage(V)

    AC660V

    3

    Rated frequency(Hz)

    50

    4

    Main Bus Rated Current (A)

    ≤6300

    5

    Distribution Bus Rated Current(A)

    ≤2200

    6

    Main Bus Rated Short-time Withstand Current (kA)

    ≤100

    7

    Distribution Bus Rated Short-time Withstand Current (kA)

    15

    8

    Rated Impulse Withstand Voltage(kV)

    8

    9

    Standard

    GB7251.12

    10

    Protection Degree

    IP30

    GCS1 fixed separated switchgear equipment

    GCS1 fixed separated switchgear equipment

    GCS1 fixed separated switchgear equipment

    GCS1 fixed separated switchgear equipmentGCS1 fixed separated switchgear equipment
